How Many Amps Can a Wago 221 Take? Acturally , It is very easy questions
You can learn directly from the body of Splicing Connectors
Whether USA or European Market and Applications
The 221’s maximum current rating will be based on its maximum conductor size , Here is chart for you:
| Item No | Connection Points | Nominal Cross-Section | IEC Approvals | UL Approvals | ||
| Nominal Voltage | Rated Current | Rated Voltage UL | Rated Current UL | |||
| 221-412 | 2 | 4mm2 / 12 AWG | 450V | 32A | 600V | 20A |
| 221-413 | 3 | 4mm2 / 12 AWG | 450V | 32A | 600V | 20A |
| 221-415 | 5 | 4mm2 / 12 AWG | 450V | 32A | 600V | 20A |
| 221-612 | 2 | 6mm2 / 10 AWG | 450V | 41A | 600V | 30A |
| 221-613 | 3 | 6mm2 / 10 AWG | 450V | 41A | 600V | 30A |
| 221-615 | 5 | 6mm2 / 10 AWG | 450V | 41A | 600V | 30A |
