873-903 Luminaire Disconnect Connector
PUSHWIRE® Connector for Luminaire Disconnect
873-903 Lumi-Nuts are molded in color coding for circuit wiring, White , Black , Red Holes. There are two connections per pole on male side for daisy chaining. The Max 20 A current capacity to support multiple fixture loads.
Two-piece contact construction featuring high grade
stainless steel spring (for contact force) and electrolytic
copper current bar (for electrical integrity)
Integrated locking latch – automatic locking with mating
of connectors – simple push down to disengage
Add to favorites
Your favorite posts saved to your browsers cookies. If you clear cookies also favorite posts will be deleted.
Material Data
Color Yellow
Insulating Material PA66
Clamping Spring Material Chrome Nickel Spring Steel
Contact Material Copper
Rating per IEC/EN 60664-1
Rated Voltage (II/3) 400V
Rated Impulse Voltage (II/3) 4kV
Rated Current 6A
Connection Data
Connection Technoloty PUSHWIRE
Solid Conductor 0.75-4mm2 / 18-12 AWG
Stranded Conductor 1.5-2.5mm2 /16-12 AWG
Strip Length 11-13mm
No of Poles 3
Geometrical Data
Width 19mm
Height 13.2mm
Depth 42mm
For more details ,Welcome to visit : 873-903
